Datapath VSN900 Series Quick Start Manual

Wall controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Datapath UK and Corporate Headquarters
Bemrose House, Bemrose Park
Wayzgoose Drive
Derby, DE21 6XQ
England
+44 (0) 1332 294441
sales@datapath.co.uk
Datapath North America
2550 Blvd of the Generals
Suite 320
Norristown, PA 19403
USA
+1 484 679 1553
sales@datapath.co.uk
Datapath France
+33 (1)3013 8934
sales-fr@datapath.co.uk
Datapath Germany
+49 1529 009 0026
sales-de@datapath.co.uk
Datapath China
+86 187 2111 9063
sales-cn@datapath.co.uk
Datapath Japan
+81 (0)80 3475 7420
sales-jp@datapath.co.uk
Product
Classification
Version Number
VSN 900 / 1100 series Quick Start Guide
Released
1.0.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSN900 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Datapath VSN900 Series

Summary of Contents for Datapath VSN900 Series

  • Page 1 Datapath UK and Corporate Headquarters Bemrose House, Bemrose Park Wayzgoose Drive Derby, DE21 6XQ England +44 (0) 1332 294441 sales@datapath.co.uk Datapath North America 2550 Blvd of the Generals Suite 320 Norristown, PA 19403 +1 484 679 1553 sales@datapath.co.uk Datapath France +33 (1)3013 8934 sales-fr@datapath.co.uk...
  • Page 2 Quick Start Guide VSN900 and VSN1100 Series Controllers Thank you for purchasing the Datapath VSN 900 / 1100 series wall controller. The aim of this document is to quickly guide you through the process of initial setup. For detailed instructions consult the system User Guide which can be found on the Recovery Media.
  • Page 3 Note: VSN Expansion units may have been purchased as part of a large system or ordered separately. Each Datapath system is custom built and therefore the number and type of input and output cards will differ from system to system.
  • Page 4 EU – Class A Declaration of Conformity Datapath Ltd declares that this product complies with the essential requirements and other relevant provisions of Directives 2014/30/EU, 2014/35/EU and 2011/65/EU. A copy of our Declaration of Conformity is available on request. Datapath Limited...
  • Page 5 To open a video window click and drag an active capture into the Wall Control application. Use the Help Menu for a comprehensive guide to the features of the Wall Control application. Page 10...

  • Page 6: Step 2 Keyboard And Mouse

    STEP 2 KEYBOARD AND MOUSE Connect Keyboard and Mouse to USB Ports. STEP 3 CONNECT EXPANSION UNIT (OPTIONAL) HLink-G3 Connect the HLink-G3 card to the SLink-G3 card using the ExCable. (ExCable-G3, packaged and shipped with the expansion unit). SLink Card Page 3...

  • Page 7: Step 4 Connect To A Network (Optional)

    STEP 4 CONNECT TO A NETWORK (OPTIONAL) STEP 5 CONNECTING INPUT SOURCES Each Datapath system is custom built and therefore the number and type of input will differ from system to system. Contained with this Quick Start Guide are PCIe card product leaflets which give details on how the cards are connected and any supplied cables and adapters.

  • Page 8: Step 11 Wall Control (Optional)

    STEP 11 WALL CONTROL (OPTIONAL) Start | All Programs | Wall Control | Wall Control-My Computer The icons displayed in the application toolbar identify which type of source is available to each input Icons highlighted green indicate an active capture for that particular input.

  • Page 9: Step 9 Activate Windows 7

    STEP 10 DISPLAY SETUP All Datapath wall controllers have pre-configured settings for the wall layout and screen resolution. Change settings using the TWIN tab: Start | Control Panel | Appearance and Personalization | Adjust screen resolution.
  • Page 10 STEP 6 CONNECT CONTROL SCREEN (OPTIONAL)/ MONITORS 3 x 2 Video Wall 4 x 2 Video Wall Control Screen (Optional) Monitor 1 Monitor 2 Monitor 3 Monitor 4 Monitor 5 Monitor 6 Monitor 7 VGA/DVI Monitor 8 Connect graphic outputs to monitors using DisplayPort cables.

  • Page 11: Step 7 Powering Up The System

    STEP 7 POWERING UP THE SYSTEM Connect power cables then plug into a mains supply. Switch on the power supply units. Switch on the system. If you have an VSN Expansion Chassis connected to the main unit then the power supply units on the expansion chassis should be switched on prior the main unit.

  • Page 12: Step 8 Windows 7 Setup

    STEP 8 WINDOWS 7 SETUP The Product key can be located inside the door of the controller. Computer Name: t is recommended that only Internet-standard characters are used in the computer name. The standard characters are the numbers 0 through to 9, upper and lower-case letters from A through to Z and the hyphen character.
