Chapter 4 - Hardware
4.1 VSN400
4.1.1 Front
5
4.1.2 Rear
R4
R4
Hardware
2
3
4
1
6
7
Front Panel
1 = Power, on-off
2= System Reset
3= Power LED
4= SSD LED
R1
R2
Rear Panel - RPSU
R1
R2
Rear Panel - ATX
R1= Power Switch
R2= USB Ports
5= PSU Reset LED
6= PSU Alarm
7= USB Ports
8= Removable Hard Drives
R3= Ethernet Ports
R4= HDMI/DisplayPort
Outputs
