MODBUS MAP:

On Modbus side, the map is created automatically.
Data in reading:
Input Register
Input Register
Input Register
Input Register
Data in writing:
Holding Register
Holding Register
Holding Register
Holding Register
Note:
The data can be read/written as single bits too using Input/Coil Status (Function 02 and Functions 01/05/15).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Type Address
0
1
2
.
749
Type Address
0
1
2
.
749
User Manual OPC UA Server / Modbus TCP Slave
Document code: MN67B30_ENG
Function Description
Input Bytes (Position) 0-1 of internal array
04
Input Bytes (Position) 2-3 of internal array
04
Input Bytes (Position) 4-5 of internal array
04
Input Bytes (Position) 1498-1499 of
04
internal array
Function Description
R: 03
Output Bytes 0-1 of internal array
W: 06/16
R: 03
Output Bytes 2-3 of internal array
W: 06/16
R: 03
Output Bytes 4-5 of internal array
W: 06/16
R: 03
Output Bytes 1498-1499 of internal array
W: 06/16
INFO:
