Configure the Fixture

Configure SolaFrame 3000 fixtures through the onboard user interface.

Navigate the User Interface

1. Press and hold the [MODE/ESC] button until the display flashes. (The display is powered
by battery when the fixture has no power.)
2. Browse the menu by pressing the up, down, left, or right navigation buttons.
3.
Press the Enter button
4. Modify the selection by pressing the up, down, left, or right navigation buttons according
to the selection.
5. Press the Enter button
6. To exit the menu, press the [MODE/ESC] button.
Note:
the user interface returns to the default display after 10 seconds.
14
to select a menu item.
to confirm a modified selection.
If you press the Enter button to confirm a selection and push no other buttons,
