Kubota B2301 Workshop Manual page 319

B2301, B2601, WSM
Symptom
Illumination Light
Does Not Light
Hazard Light (Tail
Light) Does Not Light
Hazard Indicator
Lamp (Turn Signal
Lamp) Does Not Light
Hazard Light (Tail
Light) Does Not
Flicker
Turn Signal Light
Does Not Light
Turn Signal Light
Indicator Lamp Does
Not Light
Turn Signal Light
Does Not Flicker
Probable Cause and
Checking Procedure
1. Fuse blown (15 A)
2. Bulb blown
3. Wiring harness
disconnected or
improperly connected
(between key switch AC
terminal and combination
switch terminal, between
combination switch T
terminal and panel board)
1. Fuse blown (15 A)
2. Bulb blown
3. Wiring harness
disconnected or
improperly connected
4. Flasher unit damaged
5. Hazard switch damaged
1. Bulb blown
2. Wiring harness
disconnected or
improperly connected
1. Flasher unit damaged
1. Fuse blown (10 A)
2. Bulb blown
3. Wiring harness
disconnected or
improperly connected
4. Flasher unit damaged
5. Combination switch
damaged
1. Bulb blown
2. Wiring harness
disconnected or
improperly connected
(between combination
switch R or L terminal and
panel board)
1. Flasher unit damaged
Solution
Replace fuse
Replace bulb
Repair or replace connector and wire
harness
Repair wire harness or other
Replace bulb
Repair or replace connector and wire
harness
Replace flasher unit
Replace combination switch
Replace bulb
Repair or replace connector and wire
harness
Replace flasher unit
Repair wire harness or other
Replace bulb
Repair or replace connector and wire
harness
Replace flasher unit
Replace combination switch
Replace bulb
Repair or replace connector and wire
harness
Replace flasher unit
8-S5
ELECTRICAL SYSTEM
Reference
Page
G-34
G-34
8-M1
G-34, 8-M1
G-34
8-M1
8-S20
8-S18
G-34
8-M1
8-S20
8-M1
G-34
8-M1
8-S20
8-S18
G-34
8-M1
8-S20
KiSC issued 11, 2014 A
