Kubota B2620 Instruction Manual

Rops cab
Hide thumbs Also See for B2620:

Advertisement

Quick Links

Download this manual
June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual
Kubota B2320 Series ROPS Cab
This ROPS cab is designed and built to fit the Kubota B2320, B2620, and B2920.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product warranty provided by Tektite.
Kubota B2320 Series ROPS Cab
** Plastic topped cab is shown with optional equipment

Advertisement

loading
Need help?

Need help?

Do you have a question about the B2620 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kubota B2620

Summary of Contents for Kubota B2620

  • Page 1 Kubota B2320 Series ROPS Cab ** Plastic topped cab is shown with optional equipment Kubota B2320 Series ROPS Cab This ROPS cab is designed and built to fit the Kubota B2320, B2620, and B2920. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 2 DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW 1) Always wear personal protective equipment 2) A minimum of two people is necessary to safely install the cab 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 3 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota B2320 series ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 4 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual Parts List Standard Cab: Description Bolt, Flange, 5/8” x 1 ½”, Gr. 8, YD (Loader only) Nut, Flange, 5/8”, Gr. 8, YD (Loader only) Front Brackets (Loader Configuration) L&R Bolt, Flange, 5/8”...
  • Page 5 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual...

  • Page 6: Installation Instructions

    June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual Installation Instructions: 1. Remove upper hoop of the two-post ROPS from machine. Take care during installation as there will be a lot of pressure on the entire assembly. 2. Mark the wires going to both seat switches first, and then disconnect the wiring harness from both switches.
  • Page 7 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 8. Fasten shield into place with factory hardware at the front first. 9. Re-install the seat track assembly. TIP: When installing M8 bolts, use a small nut (ie 10-24) as a spacer between the driver socket and the bolt to make installation easier and allow you to put more pressure down onto the bolt while installing it.
  • Page 8 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 10. Re-install the seat onto the seat track assembly with factory hardware. 11. For tractors equipped with the LA304 front end loader, take the left front bracket and bolt to the outside of the loader mount plate shown with the provided 5/8”...
  • Page 9 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 12. For tractors equipped with the LA354 front end loader, take the left front bracket and bolt to the inside of the loader mount plate shown with the provided 5/8” x 1 ½” hex bolts and...
  • Page 10 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 13. For tractors equipped with no loader, take the provided left mounting bracket and four of M12 x 35 flange bolts and bolt onto the tractor in the bolt pattern shown below: 14.
  • Page 11 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 16. Take the provided cab lift bolts, ½” x 4 ½” hex bolts and fasten to the mount nut located at the top of the door behind the tab.
  • Page 12 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 20. Lower the cab straight down onto the front mount pad on the front bracket. Use the provided 5/8” x 3” hex bolts, ¼” structural washer, and flange nut for the front isolator.
  • Page 13 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 24. Re-install the outer seat belt mount plates with the fasteners passing through the cab shield as well. TIP: When installing bolts, use a small nut (ie 10-24) as a spacer between the driver socket and the bolt to make installation easier and allow you to put more pressure down onto the bolt while installing it.
  • Page 14 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 28. Take the left rear pedal diff lock floormat and slide through the diff lock pedal and underneath the factory floormat to cover the hole a little better. 29. Take the right rear pedal floormat and slide through the pedal and underneath the factory...
  • Page 15 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 30. Take the brake pedals floormat and slide through the brake pedals. Use the provided push button fasteners. It will be necessary to drill ¼” holes through the floormat and floor sheet- metal.
  • Page 16 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual 34. Use the provided zip ties to secure the hoses as best as possible. 35. Drain the engine antifreeze. 36. Locate the bypass hose on top of the engine and remove.
  • Page 17 June 2021© Kubota B2320 Series ROPS Cab Steel Top Installation Manual This bracket upside down Rotate bracket 180° As shown here...
  • Page 18 June 2021© Kubota B2320 Steel Top Operation Manual Kubota B2320 Series Cab ** Kubota B2601 Shown for reference Kubota B2320 Series Cab This ROPS cab is designed and built to fit the Kubota B2320, B2620, and B2920. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 19 June 2021© Kubota B2320 Steel Top Operation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota B2320 series ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 20 June 2021© Kubota B2320 Steel Top Operation Manual Tektite Limited Warranty Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from the original invoice date.

  • Page 21: Safety Precautions

    June 2021© Kubota B2320 Steel Top Operation Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.

  • Page 22: Operating Safety

    June 2021© Kubota B2320 Steel Top Operation Manual General Safety 1. Never let an unqualified or untrained driver operate the tractor. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
  • Page 23 June 2021© Kubota B2320 Steel Top Operation Manual Safe Operation on Rough Terrain 1. Drive the tractor slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
  • Page 24 June 2021© Kubota B2320 Steel Top Operation Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the tractor is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
  • Page 25 June 2021© Kubota B2320 Steel Top Operation Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the tractor. Failure to do so may result in unsafe operation of the tractor and possible injury or death to operators and bystanders.
  • Page 26 June 2021© Kubota B2320 Steel Top Operation Manual 4. Rear Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work light is on. 5. Beacon Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
  • Page 27 June 2021© Kubota B2320 Steel Top Operation Manual After your ROPS Cab has been installed: Before starting a tractor equipped with a Tektite ROPS cab: 1. Clear the operator platform of all tools. Tools left in or around the ROPS and tractor can cause operator interference which could lead to bodily injury and/or damage the machine.
  • Page 28 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0002 LEFT-LATCH Suicide Door Left Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD...
  • Page 29 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0003 RIGHT-LATCH Suicide Door Right Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD...
  • Page 30 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 THICK-BUSHING 8MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR...
  • Page 31 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 THICK-BUSHING 8MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR...
  • Page 32 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 THICK-BUSHING 8MM Bushing A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD K04-0012 KUB2320-029 Lower Front Window K04-0013 KUB2320-106_ Lower Front Window Seal Tektite Manufacturing Inc.
  • Page 33 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0046 TEKT-ASM-002R Side Window Hinge Right A00-0056 TEKT-0020 Side Window Latch, L60775 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD A00-0059 HEX-NUT-5-16 Hex, Nylon Locking Nut, 5/16", YD...
  • Page 34 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0044 TEKT-ASM-002 Side Window Hinge Weldment A00-0057 TEKT-0020MIR Side Window Latch, L60776 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD A00-0059 HEX-NUT-5-16 Hex, Nylon Locking Nut, 5/16", YD...
  • Page 35 Index Service Part # File Name Description KUB2320-ASM-39 A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0023 FLANGE_BOLT_1-4X3-4 Flange Bolt, 1/4" x 3/4", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD A00-0061 TEKT-0021 Striker Mounting Plate A00-0084 TEKT-0070 Gas Shock A00-0085 TEKT-0069 Gas Shock Stud A00-0101 STRIKER-PIN Striker Pin...
  • Page 36 Index Service Part # File Name Description A00-0024 BUSS-15600-08-11 Power Block/Ground A00-0055 TEKT-0019 Fir Tree Fastener A00-0065 TEKT-ASM-005 On-Off Switch w/Lens A00-0067 TEKT-ASM-007 Mom-Off-Mom Rocker Switch A00-0223 TEKT-ASM-013 Steel Top Switchplate w/Decal A00-0224 TEKT-0104 3" Plug, Steel Top Tektite Manufacturing Inc. 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd: CNC:...
