Advanced Poly-Packaging Advanced Poly-Bagger T-1000-S14 Operation Manuals page 90

ITEM
QTY
NO.
1 1
2 1
3 1
4 1
5 1
6 1
7 4
8 1
9 1
*NOTE: Depending on your order, Item 2 could also be TP-T1MB00009 Heater Seal Bar, TP-T1MB00009-2 1/4"
Seal Bar, TP-T1MB00009-3 Three Point Seal or TP-T1MB00009-5 3/8" Seal Bar.
88
5.10b Heater Bar Subassembly
PN: TA-T10006
PART NO.
TP-T1MB00008
TP-T1MB00009-1
TP-T1MB00006
TP-T1MB00024
TP-T1MB00145
TP-T1MB00159
TP-104124
TP-217116
TP-221416
DESCRIPTION
HEATER BAR MOUNTING PLATE
1/8" SEAL BAR*
HEATER BAR CLAMP
HEATER CARTRIDGE CORNER HANGER
WIRE TIE DOWN
HEATER CARTRIDGE WIRE LEAD CLAMP
SPACER
CARTRIDGE, HEATER
THERMAL-COUPLE WIRE
