ITEM
QTY
NO.
1
1
2
1
3
2
4
1
5
1
6
2
7
1
8
2
9
1
10
1
11
2
12
1
13
2
14
4
15
2
78
5.6 Dancer Assembly
PN: TA-T10220
PART NO.
TP-T1MA00069-1
TP-T1MA00069-2
TP-T1MA00072
TP-T1MA00073
TP-T1MA00186
TP-504132
TP-T1MA00081
TA-T10010
TP-109212
TP-T1MA00115
TP-104148
TP-103583
TP-T1MA00089
TP-504101
TP-T1MA00090
DESCRIPTION
DANCER SIDE PLATE
DANCER SIDE PLATE
DANCER TENSION BAR
BAG ROLL SHAFT
TENSION ADJUSTER
CAM FOLLOWER
DANCER TENSION BAR CROSS BRACE
FILM TENSION HUB ASSEMBLY
KNOB
BELT TENSION STRAP AND SPRING
SPACER
SHOULDER BOLT
DANCER ROLLER
ROLLER BEARING
DANCER GUIDE ROLLER SHAFT
