4.22 PLC IO Listing

Main PLC and Expansion PLC IO (Inputs and Outputs) listing is provided to assist in troubleshooting the
T-1000-S14.
Main PLC
Input
X0
X1
X2
X3
X4
X5
X6
X7
X8
X9
XA
XB
XC
XD
XE
XF
Expansion PLC
Input
X20
X21
X22
X23
X24
X25
X26
X27
X28
X29
X2A
X2B
X2C
X2D
X2E
X2F
56
Description
Reserved for Stepper control
Perf Sensor
Not Used - Available
AF10 HomeSensor
Jam Detect Sensor
CF-10 Part Counting Eye
Auxiliary In
Seal Bar In Sensor
Foot Switch
Out of Bags Sensor
Frame Open Sensor
TI1k Printer Ready
TI1k Printer Error
Palm Button Left
Palm Button Right
Aux Fault
Description
UF5K Flight Sensor
UF5K Part Sensor
UF5k Drive Alarm
UF5K Aux In
E-Stop
Light Curtain Signal
DF-20 Eye
Spare
Dumper Home Sensor
Dumper Out Sensor
MV-10 Temperature Alarm
MV-10 Pressure Alarm
BCVer NO Error
BO-30 Bag Open Sensor
BO-30 Home Sensor
Spare
Output Description
Y0 Stepper PulseTrain CW
Y1
Stepper PulseTrain CCW
Y2
H/V Trigger
Y3
Heater control
Y4
Air Blower Solenoid
Y5
Air Pulse Solenoid
Y6
Heater Bar Solenoid
Y7
Seal Bar Out Solenoid
Y8
Seal Bar In Solenoid
Y9
Blow Off Solenoid
YA
TIZ NBO Print Request
YB
Station #5 Solenoid
YC
HV Armed (for 220V)
YD
LC-10 Power Relay
YE
TIZ OFL Print Request
YF
Auxiliary Out
Output Description
Y20
UF5k Run
Y21
UF5k Auxiliary Out
Y22
Good Bag
Y23
Med Flat Seal Down Solenoid
Y24
Med Flat Seal Out Solenoid
Y25
Stack Light Red
Y26
Stack Light Amber
Y27
Stack Light Green
Y28
Station #6 Solenoid
Y29
Station #7 Solenoid
Y2A
Station #8 Solenoid
Y2B
Station #9 Solenoid
Y2C
Station #10 Solenoid
Y2D
Base Height UP Solenoid
Y2E
Base Height DOWN Solenoid
UF5k: Conveyor Drive Alarm
Y2F
Reset
