Main Frame Assembly - Advanced Poly-Packaging Advanced Poly-Bagger T-1000-S14 Operation Manuals

ITEM
QTY
NO.
1 2 TP-T1MC00001S14NB
2 2
3 1 TP-T1MC00042NB
4 1
5 1
6 4
7 2
8 2
9 2
10 1
11 1
12 2
13 1
14 2
15 2
16 4
17 4
18 4
19 2
20 1
21 1
22 1
23 2
24 2
25 1 TP-T1MD00010S14
26 1
27 1

5.8 Main Frame Assembly

PN: TA-T10250-S14
PART NO.
TP-T1MC00044
TP-T1MC00079
TP-T1MC00056
TP-T1MC00054
TP-T1MC00099
TP-T1MC00058
TP-T1MC00059
TP-T1MC00163-2
TP-T1MC00163-1
TP-504113
TP-T1MC00017
TP-T1MC00082
TP-T1MC00052
TP-106106
TP-108099
TP-504101
TP-111010
TP-501170
TP-T14M1027
TP-T1MC00161
TP-111142
TP-215200
TA-T10002-S14
TP-502104
DESCRIPTION
SIDE FRAME
FACE PLATE BLOCK
FACE PLATE
CYLINDER PIVOT SHAFT
REAR CROSS SUPPORT SHAFT
COVER SUPPORT CLAMP
REAR COVER SUPPORT
LATCH ADJUSTER BLOCK
LATCH LOCK BLOCK
GUIDE BLOCK - RH
GUIDE BLOCK - LH
BEARING
RUBBER ROLLER
COVER STAND-OFF
GUIDE ROLLER
SPRING PINS
COMPRESSION SPRING, 0.040 GAUGE, 0.359 OD
BEARING
SPRING CLOSURE COLLAR
S14 STEPPER MOTOR
MOTOR PULLEY
DRIVEN PULLEY
CLAMP, COLLAR
MAGNETIC SWITCH, T-1000-S14 MACHINE OPEN
SENSOR
PNEUMATICS BACK PANEL
UPPER ROLLER ASSEMBLY
BELT 210XL037
81
