Save & Exit - Nexcom NEX 614A User Manual

Chapter 3: BIOS Setup
Quiet Boot
Enabled Displays OEM logo instead of the POST messages.
Disabled Displays normal POST messages.
Boot Mode Select
Configures the boot mode option.
Boot Option #1 to Boot Option #8
Adjust the boot sequence of the system. Boot Option #1 is the first boot
device that the system will boot from, next will be Boot Option #2 and so
forth.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Save & Exit
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main Advanced Chipset
Save Options
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Default Options
Restore Defaults
Boot Override
Launch EFI Shell from filesystem device
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
Save Changes and Exit
To save the changes and exit the Setup utility, select this field then press
<Enter>. A dialog box will appear. Confirm by selecting Yes. You can also
press <F4> to save and exit Setup.
Discard Changes and Exit
To exit the Setup utility without saving the changes, select this field then
press <Enter>. You may be prompted to confirm again before exiting. You
can also press <ESC> to exit without saving the changes.
Save Changes and Reset
To save the changes and reset, select this field then press <Enter>. A dialog
box will appear. Confirm by selecting Yes.
44
Security Boot Save & Exit
Reset the system after saving
the changes.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
NEX 614A User Manual
