Chapter 3: BIOS Setup

PCI Express Configuration

Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCI Express Configuration
► PCI Express Root Port 1
PCIE Port 5 is assigned to LAN1
PCIE Port 6 is assigned to LAN2
► PCI Express Root Port 9 (Mini Card)
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
PCI Express Root Port 1
Settings for PCI Express root port 1.
PCI Express Root Port 9 (Mini Card)
Settings for PCI Express root port 9.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
PCI Express Root Port 1
PCI Express Root Port 1
Settings.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PCI Express Root Port 1
Enables or disables PCI Express root port 1.
ASPM
Configures the ASPM level.
Force L0s
AUTO
DISABLE
PCIe Speed
Configures the speed of the PCI Express port.
Detect Non-Compliance Device
Enables or disables detection of non-compliance PCI Express device. If
enabled, POST will take more time.
40
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCI Express Root Port 1 [Enabled]
ASPM [Disabled]
PCIe Speed [Auto]
Detect Non-Compliance Device [Disabled]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
Force all links to L0s state.
BIOS auto configuration.
Disables ASPM
Control the PCI Express Root
Port.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
