Chapter 3: BIOS Setup
USB Configuration
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main Advanced Chipset Security
USB Configuration
XHCI Disable Compliance Mode [FALSE]
xDCI Support [Disabled]
USB Port Disable Override [Disabled]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
XHCI Disable Compliance Mode
Enables or disables XHCI link compliance mode. Setting FALSE will not disable
link compliance mode, while setting TRUE will disable link compliance mode.
xDCI Support
Disables or disables xDCI support (USB OTG Device).
USB Port Disable Override
Enables or disables the USB port from reporting a device connection to the
controller.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
Boot Save & Exit
Options to disable Compliance
Mode. Default is FALSE to not
disable Compliance Mode. Set
TRUE to disable Compliance
Mode.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
HD Audio Configuration
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Main Advanced Chipset
HD Audio Subsystem Configuration Settings
HD Audio
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
HD Audio
Control detection of the HD-Audio device.
Disabled HDA will be unconditionally disabled.
Enabled HDA will be unconditionally enabled.
Auto HDA will be enabled if present, disabled otherwise.
42
Security Boot Save & Exit
Control Detection of the
HD-Audio device.
Disabled = HDA will be
[Auto]
unconditionally disabled
Enabled = HDA will be
unconditionally enabled
Auto = HDA will be enabled if
present, disabled otherwise.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
