Chapter 3: BIOS Setup
PCI Express Root Port 9 (Mini Card)
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCI Express Root Port 9 [Enabled]
ASPM [Disabled]
PCIe Speed [Auto]
Detect Non-Compliance Device [Disabled]
Version 2.18.1263. Copyright (C) 2017 American Megatrends, Inc.
PCI Express Root Port 9
Enables or disables PCI Express root port 9.
ASPM
Configures the ASPM level.
Force L0s Force all links to L0s state.
AUTO BIOS auto configuration.
DISABLE Disables ASPM
PCIe Speed
Configures the speed of the PCI Express port.
Detect Non-Compliance Device
Enables or disables detection of non-compliance PCI Express device. If
enabled, POST will take more time.
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
SATA And RST Configuration
Control the PCI Express Root
Port.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
SATA Controller(s)
Enables or disables the SATA controller.
SATA Mode Selection
Configures the SATA mode. The options are AHCI and Intel RST Premium.
Port 0, M.2 Port and Port 2
Enables or disables SATA port 0, M.2 port or SATA port 2.
41
Aptio Setup Utility - Copyright (C) 2017 American Megatrends, Inc.
Advanced
SATA And RST Configuration
SATA Controller(s) [Enabled]
SATA Mode Selection [AHCI]
Serial ATA Port 1 Empty
Software Preserve Unknown
Port 1 [Enabled]
M.2 SATA Port Empty
Software Preserve Unknown
M.2 Port [Enabled]
Serial ATA Port 2 Empty
Software Preserve Unknown
Port 2 [Enabled]
Version 2.17.1255. Copyright (C) 2017 American Megatrends, Inc.
Enable/Disable SATA Device.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
