System Overview

The Enforcer is the first two-way wireless high security wireless system on the market. It can only be
compared to an addressable wired system, but instead of using a wired data bus it uses a wireless
one.
All devices can cover a wireless range of open space up to 1.6km.
System Overview
Full Areas
Sub Areas (Readers)
Wireless Inputs (max)
Wired Inputs On-board
Wired Inputs (max)
Total Inputs Wireless and Wired
On-board Outputs
User Automation Outputs
Outputs (max)
User Codes and Tags
Wireless Keyfobs (max)
Duress / Guard Codes
Communications Modules
Additional Wired Arming Devices (max)
Additional Wireless Keypads
Logs
Memory Type
Event Signaling to UDL
Compliant to EN Grade*
Environmental Class
* EN50131 compliance labeling should be removed if non-compliant configurations are used.
Default Codes
Master Manager Code: 1234
Engineer Code: 9999
Technical functions for example fire, gas and flooding are not security graded as they are
outside the scope of EN50131-1 and EN50131-3
8 Enforcer Installation Guide
Quantity Additional Information
4
3
64
2
34 4x RIX Expanders
66
3
30
34 16 x (1 x ROX)
12 x (4 x RIX)
3 x (Keypads/Readers)
75
32 4294967295 encrypted rolling code
10
DIGI-GPRS, DIGI-LAN, DIGI-1200 (PSTN), DIGI-WIFI
3 Keypads/Readers
4
750 Time and Date
EEPROM
Yes Only via RS232
2
II
