1. Loosen the two screws located at the bottom.
Do not fully unscrew as these can be used as a 'hanger' to the rear casing as shown in step 3.
2. Unhinge the Enforcer from the top and pull down to disconnect.
Take extra care when removing the front of the Enforcer as modems, I/O boards etc may be
connected to the front.
3. Tilt the front of the Enforcer forward 180 degrees and hang it on the opening screws if required.

Connecting or Replacing the Enforcer Battery

The Enforcer back up battery must be replaced by the manufacturer's recommendation.
The part code for this battery is BATT-ENF8XAA. The battery is a NiMH 8 cell 2200mAh
rechargeable.
