eBOX532-100-FL Series User's Manual
 O.S. Supported
The eBOX532-100-FL supports Windows
®
such as Windows XP embedded and Linux. For storage device, the eBOX532-100-FL
supports one 2.5" SATA-600 HDD drive bay, and one type II CompactFlash
 ATX or AT Mode Selection Jumper (JP6)
If JP6 is enabled for power input, the system will be automatically power on without pressing
soft power button. If JP6 is disabled for power input, it is necessary to manually press soft
power button to power on the system.
Function
Disable auto power on (ATX Mode)
Enable auto power on
NOTE This function is similar to the feature of power on after power failure,
which is controlled by hardware circuitry instead of BIOS.
NOTE Once the Jumper is changed to AT model, the system power switch is no
longer usable and system will power-on once DC power enter system.
Therefore, customer needs to have external power switch to switch on/off
the system (because eBOX532's power switch is no longer workable at AT
mode).
2
®
XP, Windows 7 and also supports embedded OS,
(AT Mode)
Setting
1-2 close
1-2 open
™
slot.
Introduction
