AXIOMTEK eBOX560-880-FL Quick Installation Manual

Installing the SO-DIMM Memory
Step 1 Turn off the system, and unplug the power cord.
Step 2 Turn the system upside down to locate screws at the bottom,
loosen screws.
Step 3 Remove the bottom cover and HDD bracket.
Step 4 Please find the DRAM position then insert memory carefully.
Step 5 Finally , fasten the HDD bracket and bottom cover to complete
installation.
Note:
Please refer to the user's manual to get more detail information.
4 ©Copyright 2014 Axiomtek Co., Ltd.
Version A1 Sep 2014
Printed in Taiwan
9416K560000E
eBOX560-880-FL Quick Installation Guide
Packing List
System Unit x 1 DVD/CD x 1 (for Driver & Manual)
Quick Installation Guide x 1 Foot Pad x4
Screws Pack x 1 12V AC to DC Adapter x1
Optional SSD/HDD Optional Wall-mount kit
Optional mSATA Optional Din-rail & VESA kit
Optional Mini Card Modules Optional DRAM

Do not try to apply power to the system if any damaged components.
Dimensions
©Copyright 2014 Axiomtek Co., Ltd.
Version A1 Sep 2014
Printed in Taiwan
9416K560000E
