The scheme presented in this section is the simplest implementation of 3axis plotter (XYZ).
Two power supplies were used: 24V to supply the CSMIO/IP-S controller and 80V for the stepper
motors drives. Switches used: normally close (NC) switches for axis homing (HOME) and limit switch-
es (LIMIT). In practice, it is necessary to build more complex systems, however the example above
shows the main rule.
C S - L a b s . c . – C S M I O / I P - S - C N C C o n t r o l l e r
Page 31
