mouse button and select "Properties". On "General" tab enter any name e.g. "MyMillingMachine",
go to the „Shortcut" tab and in the „Target element" enter:
C:\Mach3\Mach3.exe /p MyMillingMachine_400x250_CSMIO_IP
Type the special signs „/"and „\" carefully, in correct places. You can type any other name of course
instead of "MyMillingMachine..." but it must be identical as your profile name.
After all click „OK" and now, you can launch the program using the shortcut you have just created.

10.2 The first run

Before that, you should connect Ethernet cable of the controller to a computer or plug it into a com-
puter network. You must switch the controller power ON at least 10 seconds earlier.
If plugin for CSMIO/IP-S was installed properly, as described in the chapter 9 - then there should this
window appear:
Before you start other parameters configuration, you can verify if communication with the controller
is correct. Click on the „Plugin Control" top menu and select the „ CSMIO_IPplugin" position.
C S - L a b s . c . – C S M I O / I P - S - C N C C o n t r o l l e r
After you launch the program for the first
time, you will see the window of license ap-
proval.
You should fill in the check box and agree by
clicking the button as shown in the picture.
Select motion controller type –
„CSMIO_IP/P" and fill in the check
box: „Don't ask me again", so
Mach3 in this configuration profile
will always use CSMIO/IP-S control-
ler. Confirm your selection with
"OK".
