ADV7511W

Overview

1.2
The ADV7511W is a high speed High Definition Multimedia Interface (HDMI) transmitter that is capable of
supporting an input data rate up to 165MHz (1080p @ 60Hz, UXGA @ 60Hz). Careful hardware design (schematics
and PCB layout) is recommended to optimize the performance and to ensure HDMI compliance.
▷ The ADV7511W Programming Guide and ADV7511W Software Driver User Guide are also available if required.

Hardware Features

1.3
■ HDMI v1.4 features supported
■ Operation up to 165MHz (TMDS link frequency)
■ Integrated CEC support with 3 message buffers
■ Supports x.v.Color™ (Gamut Metadata)
■ Internal HDCP key storage
■ Interrupt (INT) output pin eliminates constant I2C monitoring
■ Supports I2S, S/PDIF and HBR audio input formats
■ No audio Master Clock (MCLK) required for audio
■ Requires 1.8V and 3.3V supply
■ EDID buffered on chip
■ Color Space Converter (CSC) with video range clipping
■ 64-lead LQFP package
■ -40°C to +105°C temperature range

Supported Input Formats

1.4
■ 24 bit RGB 4:4:4 (separate syncs)
■ 24 bit YCbCr 4:4:4 (separate syncs)
■ 24, 20, or 16 bit YCbCr 4:2:2 (embedded or separate syncs)
■ 12, 10, or 8 bit YCbCr 4:2:2 (2x pixel clock with embedded or separate syncs)
■ 12, 10, or 8 bit YCbCr 4:2:2 (DDR with embedded or separate syncs)

Supported Output Formats

1.5
■ 24 bit RGB 4:4:4
■ 24 bit YCbCr 4:4:4
■ 24 bit YCbCr 4:2:2
Page 8
of 45
3D video
Advanced Colorimetry
•
sYCC601
•
Adobe RGB
•
Adobe YCC601
HARDWARE USER'S GUIDE
Rev.A
Rev A
