ADV7511W
■ Stop signal
Serial Interface—Typical Byte Transfer
Figure 20
SDA
SCL
Power Domains
6.7
All power domains of the ADV7511W operate off of 1.8 volts, with the exception of the DVDD_3V which is 3.3 volts.
It is recommended that the ADV7511W has its own designated 1.8V linear regulator and that the PVDD, AVDD and
DVDD PCB power domains be segregated using inductors as illustrated in ▶ Figure 21. More detailed
recommendations for the PCB can be found in section ▶ Section 7:.
Power Supply Domains
Figure 21
1.8V
LDO
3.3V
LDO
Page 39
of 45
BIT 6
BIT 5
BIT 4
BIT 7
10uH
10uF
10uH
10uF
10uH
10uF
10uH
10uF
BIT 3
BIT 2
BIT 1
BIT 0
DVDD
AVDD
PVDD
HARDWARE USER'S GUIDE
ACK
Pin 1
DVDD
Pin 11
DVDD
Pin 31
DVDD
Pin 51
DVDD
Pin 15
AVDD
Pin 19
AVDD
Pin 25
AVDD
All bypass capacitors 0.1uF
Pin 13
BGVDD
Pin 12
PVDD
Pin 29
DVDD_3V
Rev. A
Rev A
