Table 5 Normal Rgb Or Ycbcr 4:4:4 (24 Bits) With Separate Syncs; Input Id = 0 - Analog Devices ADV7511W Hardware User's Manual

ADV7511W HARDWARE USER'S GUIDE
Rev. A
Normal RGB or YCbCr 4:4:4 (24 bits) with Separate Syncs; Input ID = 0
Table 5
Input Data<23:0>
Format
23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RGB 444 R[7:0] G[7:0] B[7:0]
YCbCr 444 Cr[7:0] Y[7:0] Cb[7:0]
An input format of RGB 4:4:4 or YCbCr 4:4:4 can be selected by setting the input ID (R0x15[3:0]) to 0. There is no need to set
the Input Style (R0x16[3:2]).
