Intel® Server System R2000LH2/T2 Product Family TPS
Light pipes integrated into the drive tray assembly direct light emitted from Amber drive status
and Green activity LEDs located next to each drive connector on the backplane, to the drive tray
faceplate, making them visible from the front of the system.
Power on with no
drive activity
Power on with
drive activity
Green
Power on and
drive spun down
Power on and
drive spinning up
Revision 1.0

Figure 28. 2.5" Hard Disk Drive Assembly

Figure 29. 2.5" Drive LEDs

Table 26. 2.5" Drive Status LED States

Off
Solid On
Amber
Blink

Table 27. 2.5" Drive Activity LED States

Condition Drive Type
SAS
SATA
SAS
SATA
SAS
SATA
SAS
SATA
System Storage and Peripheral Drive Bays Overview
No access and no fault
Hard Drive Fault has occurred
RAID rebuild in progress (1 Hz),
Identify (2 Hz)
Behavior
LED stays on
LED stays off
LED blinks off when processing a command
LED blinks on when processing a command
LED stays off
LED stays off
LED blinks
LED stays off
45
