Intel® Server System R2000LH2/T2 Product Family TPS
On the back side of each backplane are several connectors. The following illustration identifies
each.
Revision 1.0
Figure 38. 3.5" Drive Hot-Swap Backplane – Back Side
Label
A
Power connector
B
SGPIO connector
2
C
I
C connector
C
SATA connectors
System Storage and Peripheral Drive Bays Overview
Description
51
