PCI-DAS08 User's Guide
Pin Signal Name
1 +12V
2 CTR1 CLK
3 CTR1 OUT
4 CTR2 CLK
5 CTR2 OUT
6 CTR3 OUT
7 DOUT1
8 DOUT2
9 DOUT3
10 DOUT4
11 DGND
12 LLGND
13 LLGND
14 LLGND
15 LLGND
16 LLGND
17 LLGND
18 LLGND
19 10V REF
Table 4-7. Main connector pin out
Pin Signal Name
20 -12V
21 CTR1 GATE
22 CTR2 GATE
23 CTR3 GATE
24 EXT IN
25 DIN1
26 DIN2
27 DIN3
28 DGND
29 +5V
30 CH7
31 CH6
32 CH5
33 CH4
34 CH3
35 CH2
36 CH1
37 CH0
