config 802.1x capability ports
Restrictions
Example usage:
To configure 802.1x capability on ports 1-10:
DGS-3400:4#config 802.1x capability ports 1 – 10 authenticator
Command: config 802.1x capability ports 1 – 10 authenticator
Success.
DGS-3400:4#
config 802.1x auth_parameter
Purpose
Syntax
Description
Parameters
xStack DGS-3400 Series Layer 2 Gigabit Managed Switch CLI Manual
all − Specifies all of the ports on the Switch.
authenticator − A user must pass the authentication process to gain
access to the network.
none − The port is not controlled by the 802.1x functions.
Only administrator-level users can issue this command.
Used to configure the 802.1x Authentication parameters on a range of ports.
The default parameter will return all ports in the specified range to their default
802.1x settings.
config 802.1x auth_parameter ports [<portlist> | all] [default | {direction
[both | in] | port_control [force_unauth | auto | force_auth] | quiet_period
<sec 0-65535> | tx_period <sec 1-65535> | supp_timeout <sec 1-65535> |
server_timeout <sec 1-65535> | max_req <value 1-10> | reauth_period
<sec 1-65535> | enable_reauth [enable | disable]}]
The config 802.1x auth_parameter command is used to configure the 802.1x
Authentication parameters on a range of ports. The default parameter will
return all ports in the specified range to their default 802.1x settings.
<portlist> − Specifies a port or range of ports to be configured.
all − Specifies all of the ports on the Switch.
default − Returns all of the ports in the specified range to their 802.1x default
settings.
direction [both | in] − Determines whether a controlled port blocks
communication in both the receiving and transmitting directions, or just the
receiving direction.
port_control − Configures the administrative control over the authentication
process for the range of ports. The user has the following authentication
options:
force_auth − Forces the Authenticator for the port to become
•
authorized. Network access is allowed.
−
auto
•
authentication process.
force_unauth − Forces the Authenticator for the port to become
•
unauthorized. Network access will be blocked.
quiet_period <sec 0-65535> − Configures the time interval between
authentication failure and the start of a new authentication attempt.
tx_period <sec 1-65535> - Configures the time to wait for a response from a
supplicant (user) to send EAP Request/Identity packets.
supp_timeout <sec 1-65535> - Configures the time to wait for a response from
a supplicant (user) for all EAP packets, except for the Request/Identity
packets.
server_timeout <sec 1-65535> - Configure the length of time to wait for a
Allows the port's status to reflect the outcome of the
