Chapter 4: How To Use The Windows Software Spectroconnect; Software Description; Installation - Techkon SpectroDrive Manual

Chapter 4
How to use the Windows software SpectroConnect

4.1 Software description

make device specific settings from the PC. The measurement values can be displayed
on the computer monitor. Color information is displayed, colors can be compared
and data can be exported into other software applications, e.g. Microsoft Excel™.
The software requires a computer with two free USB ports and a completely in-
stalled Microsoft Windows XP, Vista or 7 operating system; 32- or 64-bit;
Minimum: IBM-compatible PC with Intel Core Duo processor or comparable proces-
sor, 1 GB RAM.

4.2 Installation

It is important, to carry out the following steps in the right order, to make sure that
the USB device driver will be installed properly.
1. Make sure that the device is not connected to the PC.
Insert the SpectroConnect CD into the CD drive of the running computer.
You will find the CD at the back of this manual.
2. The installation routine will start automatically. Follow the steps of the installation,
until it is completed.
3. Now, after the installation was finished successfully you can connect the device
with the USB cable to the computer.
Manual TECHKON SpectroDrive Chapter 4 – SpectroConnect
The supplied Windows Software
SpectroConnect allows to transfer
measurement data to the PC and to
Page 63
