Inspection intervals
TECHKON SpectroDrive is to a large extend maintenance free. Nevertheless we
recommend to validate the complete functionality of the devices in a 24
months time interval in the TECHKON service center. We offer a complete device
check as a service package. Please contact us for details.
For a flat fee the device will be cleaned, checked and recalibrated. In case a repair or
exchange of components should be necessary we will inform you. Please send the
device always securely in the carrying case with complete accessories.
How to change the battery
1.
Manual TECHKON SpectroDrive Chapter 3 – How to use SpectroDrive
2.
3.
1. Open the SpectroDrive device.
A TORX™ T10 screwdriver was shipped
with the SpectroDrive unit. Use it to unscrew
the four screws as shown in the picture.
2. Disconnect the battery. To prevent dam-
ages to the battery make sure to pull only
the plug, not the cable.
3. Remove the two screws and pull out the
bridge.
4. Change the battery. Please ensure that the
cable faces the mainboard.
5. Mount the bridge (see also 3.).
6. Mount the plastic housing using the four
screws (see also picture 1).
7. Make sure that the measurement head
moves freely between its stoppers.
