4.9

Scanning Bars

Model SCANLOG only
For description, please see under «Making Reinforce-
ment Visible with CyberScan», page 14.
4.10

Measure with Grid

Model SCANLOG only
For description, please see under «Measure with Grid»,
page 17.
5

Measuring Process

5.1

Measure with Statistics

This function can be used to locate rebars, measure
concrete covers and determine bar diameters. The cover
values can be stored under object numbers.
5.1.1 Rebars Connected with Binding Wires
Settings
See also under «Settings», page 6.
• Enter the bar diameter.
If the bar diameter is unknown,
enter 16 mm.
• Enter the object number.
© 2007 Proceq SA
Limit value: To avoid confusions, set the limit value
to «0» during the measuring process. Enter the value
required for the building after completion of the series of
measurement. The percentage of the covers that are too
small will be displayed in the statistical evaluation. See
also «Detecting Insufficient Concrete Cover», page 12.
• Enter the desired audible locating aid («MENU» →
«Basic setups» → «Audible locating aid»): (Short) beep
tone or variotone.
• Enter the requested values under the menu option
«Corrections» → «Neighbouring Bar Correction» or «2-
Layer-Correction» if the correction is required.
• Select the «Measure w. Statistics» function.
• Press the START/RESET key.
Measuring Process 9
