FIG.A
FIG.B
FIG.C
IFC22906
www.powercommander.com
1
Remove the seat, fuel tank, fuel tank side panels.
2
Using the supplied velcro attach the PCFC to the left side of the airbox (Fig. A)
Make sure to clean the surface before attaching.
3
Attach the ground wire of the PCFC to the negative side of the battery (Fig. B)
4
Unplug the stock fuel injector from the wiring harness (Fig. C).
This is a BLACK, 2 pin connector near the throttle body.
13-15 Yamaha YZF-R125 - PCFC - 3
