2008-2010 Kawasaki ZX-10R
2008-2010 Kawasaki ZX-10R
I n s t a l l a t i o n I n s t r u c t i o n s
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
IFC17004.01
www.powercommander.com
2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
Parts List
Parts List
1
Power Commander FC
1
USB Cable
1
Installation Guide
2
Dynojet Decals
2
Velcro
1
Alcohol swab
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
YOU CAN ALSO DOWNLOAD THE PCFC
CONTROL CENTER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2008-2010 Kawasaki ZX-10R - 1
Advertisement
Table of Contents
Related Manuals for Dynojet POWER COMMANDER FC
Summary of Contents for Dynojet POWER COMMANDER FC
- Page 1 Parts List Parts List Power Commander FC USB Cable 2008-2010 Kawasaki ZX-10R 2008-2010 Kawasaki ZX-10R Installation Guide Dynojet Decals I n s t a l l a t i o n I n s t r u c t i o n s...
- Page 2 SELECTING THE MAP POSITION The Dynojet Power Commander Fuel Controller (PCFC) comes loaded with up to ten maps. Using a #1 Phillips screwdriver, turn the map select dial to toggle between the loaded maps. Refer to the map position table for the maps included in your PCFC.
- Page 3 FIG.A Remove the main seat and the passenger seat. Remove the covers for each side of the fuel tank as shown in Figure A. Prop the front of the fuel tank up. FIG.B Slide the junction box that is under the main seat from it’s rubber sleeve. This allows room for the PCFC harness.
- Page 4 FIG.D Attach the connectors from the PCFC to the stock wiring harness and throttle body harness as shown in Figure D. FIG.E Attach the ground wire from the PCFC harness to the stock wiring harness chassis ground as shown in Figure E. This connection is next to the PCFC connection and starter relay.
