2013 BMW R1200GS
2013 BMW R1200GS
I n s t a l l a t i o n I n s t r u c t i o n s
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
IFC12016.01
www.powercommander.com
2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
Parts List
Parts List
1
Power Commander FC
1
USB Cable
1
Installation Guide
2
Dynojet Decals
2
Velcro
1
Alcohol swab
1
Posi-tap
THE IGNITION MUST BE TURNED
OFF BEFORE INSTALLATION!
YOU CAN ALSO DOWNLOAD THE PCFC
CONTROL CENTER SOFTWARE AND
LATEST MAPS FROM OUR WEB SITE AT:
www.powercommander.com
2013 BMW R1200GS - 1
Advertisement
Table of Contents
Related Manuals for Dynojet POWER COMMANDER FC
Summary of Contents for Dynojet POWER COMMANDER FC
- Page 1 Parts List Parts List Power Commander FC USB Cable 2013 BMW R1200GS 2013 BMW R1200GS Installation Guide Dynojet Decals I n s t a l l a t i o n I n s t r u c t i o n s...
- Page 2 SELECTING THE MAP POSITION The Dynojet Power Commander Fuel Controller (PCFC) comes loaded with up to ten maps. Using a #1 Phillips screwdriver, turn the map select dial to toggle between the loaded maps. Refer to the map position table for the maps included in your PCFC.
- Page 3 FIG.A Remove the main seat. knee panel Remove the fuel injector covers and the knee panels from both sides of the bike as shown in Figure A. bat cover Remove the battery cover on the right side of the bike as shown in Figure A. FIG.B Using the supplied velcro, secure the PCFC to the top of the ECM under the seat with the wiring harness facing forward as shown in Figure F.
- Page 4 FIG.D Unplug the stock wiring harness from the left fuel injector as shown in Figure D. unplug FIG.E Attach the pair of PCFC injector leads with the orange colored wires to the left fuel injector and the stock wiring harness as shown in Figure E. Store the extra pair of connectors under the throttle body servo.
- Page 5 FIG.G Attach the ground wire with the ring lug from the PCFC to the negative side of the battery as shown in Figure G. ground Note: Make sure the ground wire is secure. FIG. H Unplug the stock wiring harness from the right fuel injector as shown in Figure H.
- Page 6 FIG.J Trace the wiring harness from the stock left O2 sensor to its connector near the side-stand as shown in Figure J. Unplug the stock left O2 sensor. unplug The stock O2 sensor will no longer be used. It can be removed from the exhaust, if desired and if you have a way to plug the hole.
