SMART CUT 2™
3 [IMAGE MENU] + ENTER.
NOTE: This menu is active only on the displayed video source. This menu is not available for the COMPUTER
inputs. The image settings and adjustments can be different and memorized for each video input.
[H position] + ENTER.
3-1
Adjust the Horizontal position with
[V position] + ENTER.
3-2
Adjust the Vertical position with
[H size] + ENTER.
3-3
Adjust the Horizontal size with
[V size] + ENTER.
3-4
Adjust the Vertical size with
[u / over scan] + ENTER.
3-5
Select Underscan or Overscan with
• [underscan] = Output image is full screen.
• [overscan] = Output image is 10% bigger than in Underscan mode.
[aspect ratio] + ENTER.
3-6
Select an Aspect Ratio with
• [4/3] = 4/3 Aspect Ratio.
• [14/9] = 14/9 Aspect Ratio.
• [16/9] = 16/9 Aspect Ratio.
[brightness] + ENTER.
3-7
Adjust the Brightness with
[contrast] + ENTER..
3-8
Adjust the Contrast with
[color] + ENTER.
3-9
Adjust the Color with
3-10 [hue] + ENTER.
Adjust the Tint of the picture (NTSC only) with
3-11 [image process] + ENTER.
Select an item with
• NO PROCESSING.
• SHARPNESS 1.
• SHARPNESS 2.
• SHARPNESS 3.
• GAMMA 1.
• GAMMA 2.
• SHARP 1 + GAMMA 1.
• SHARP 2 + GAMMA 1.
3-12 [preset] + ENTER.
• [YES] = Erases all of the Image Settings (#3-1, #3-2, ... #3-11) of the selected input and sets them back to the
• [NO] = Do not erase the Image Settings memorized.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER
+ ENTER.
+ ENTER between:
factory settings.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
Chapter 7 : LCD FUNCTIONS DESCRIPTION
