Chapter 10 : RS-232 PROGRAMMER'S GUIDE
10-5. COMMANDS DESCRIPTION (continued)
MISCELLANEOUS COMMANDS
™
- SMART CUT 2
• Y command is used to control the CUT, the AUDIO MUTE, the RESET TO DEFAULT VALUE, the FRONT
PANEL LOCK, the FREEZE...(RESPONSE : CMD----).
Bit 11 Bit 10 Bit 9
(2048) (1024) (512)
Reserved for manufacturer.
Duration of the Black Delay during a switch in Fast Cut mode.
0 = Short time (action).
1 = Long time (action).
0 = Extend switch = No (action).
1 = Extend switch = Yes (action).
NOTE: To modify an adjustment you should first read the value of the command, then modify the value of the
corresponding bit without modifying the value of the other bits, and then return the new value.
Example : If the actual adjustment is : Short, overscan, Unfreeze, Front panel unlocked, then the return value is :
Bit 11 Bit 10 Bit 9
(2048) (1024) (512)
X 0
Now if you want to lock the front panel, you should set the bit 5 to 1, without changing the value of the other bits. In this case
you should add 32 to the previous value.
• ?, K, R, L, X, commands are the status of the device's internal firmware (read only).
