Analog way Smart Cut 2 User Manual page 18

Chapter 7 : LCD FUNCTIONS DESCRIPTION
2 [OUTPUT MENU] + ENTER.
[output sync] + ENTER.
2-1
Select the Output Sync. type with
• [H&V] = H & V Separate Sync.
• [COMP] = Composite Sync.
[reference sync] + ENTER.
2-2
Select the Reference Sync. with
• [COMPUTER 1] = SMART CUT 2
• [COMPUTER 2] = SMART CUT 2
• [NO COMPUT] = Scaler mode (not Seamless), the LCD menu displays a list of output formats. Then Select
NOTE : If a SMART SWITCH VIDEO
• [COMPUTER 1] = SMART CUT 2
• [COMPUTER 2] = SMART CUT 2
• [COMPUTER 3] = SMART CUT 2
• [EXTEND PC 2] = SMART CUT 2
• [NO COMPUT] = Scaler mode (not seamless) then the LCD Menu displays a list of output formats.
[output format] + ENTER.
2-3
• If [reference sync] = [COMPUTER 1], [COMPUTER 2], [COMPUTER 3] or [EXTEND PC 2], the LCD
• If [reference sync] = [NO COMPUT], the LCD window displays a list of output format, then select an output
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA...), always select the output format corresponding
to the native resolution of the display device. Thus, the display device will not have to scale the image and
the result will be better.
[output rate] + ENTER.
2-4
• If [reference sync] = [COMPUTER 1], [COMPUTER 2], [COMPUTER 3], [EXTEND PC 2], the LCD
• If [reference sync] = [NO COMPUT] selected, select an item with
[output status] + ENTER.
2-5
• [COMP] = Composite Sync. or [H&V] = H&V Separate Sync.
• [SXGA] = Name of the Output Format.
• [64.0K / 60Hz] = Output Line Frequency / Output Frame Frequency (kHz / Hz).
PAGE 18
+ ENTER.
+ ENTER.
™
is in Seamless mode. The output is synchronized on Computer 1.
™
is in Seamless mode. The output is synchronized on Computer 2.
an output format with
™
is connected to the SMART CUT 2 ™, the LCD window displays :
™
is in Seamless mode. The output is synchronized on Computer 1.
™
is in Seamless mode. The output is synchronized on Computer 2.
™
is in Seamless mode. The output is synchronized on Computer 3.
™
is in Seamless mode. The output is synchronized on EXTEND PC 2.
window displays the "referenced" computer input.
format with + ENTER.
window displays the computer status.
• [internal rate] = Output Frame Rate = 60Hz or 75Hz depending of the selected format.
• [video in rate] = Output Frame Rate is identical to the Video Input Rate (50 Hz frame
rate if video input is PAL / SECAM / 625L or 59.94 Hz if video input
is NTSC / 525L).
+ ENTER.
SMART CUT 2™
+ ENTER.
