SMART CUT 2™

Chapter 1 : INTRODUCTION

1-1. SUPPLIED EQUIPMENT
• 1 SMART CUT 2 ™
• 1 set of 19" Brackets.
• 1 AC Power supply cord.
• 1 VGA cable (HD15 Male / Male).
• 1 S.VIDEO (Y/C) cable (mini DIN 4/mini DIN 4).
• 1 BNC (x5) to HD 15 Female cable.
• 1 set of 6 MCO (5-pins) female connectors (for audio connection).
• 1 user's Manual.
Supplied equipment with the optional RS-232 interface (SCUT 2-M).
• 1 Remote Control Software (3.5" Disk).
1-2. GENERAL INFORMATION
The SMART CUT 2
VIDEO Seamless Switcher
• It is a 5 VIDEO (2 x Composite, 2 x S.VIDEO, 1 x Component or RGB/S) and 2 COMPUTER (up to 1280 x 1024)
inputs SEAMLESS SWITCHER with a built'in SCALER.
Each VIDEO source is scaled and genlocked to match the resolution of your COMPUTER from 640 x 480 up to 1280 x
1024. The SMART CUT 2™ offers a clean and fast switching with no glitch between :
- any VIDEO and 1 COMPUTER source (in seamless mode),
- VIDEO sources (with a fast "Black Cut"),
- COMPUTER sources (with a fast "Black cut").
All video inputs are scaled to the selected computer input. This allows a "One-Time" adjustment for your display
resolution.
• The SMART CUT 2
increases the resolution and brightness of the TV image. The new High quality decoder includes an Advanced Comb
Filter, a high robust sync. detection and an improved adaptive de-interlacing scheme (for motion artifacts). It gives you
a clean "film like" native display non-interlaced image.
• Each of the 7 inputs is fitted with an STEREO AUDIO line. It allows the audio to follow your video image or to
break away from your video. The level of any audio line is separately adjustable and a Master Volume Control is
dedicated to trim the overall sound level.
™
1-3. SMART CUT 2 REFERENCES
REFERENCES
S-CUT 2
S-CUT 2-M
S-CUT 2-DILA
S-CUT 2-M-DILA SMART CUT 2
OPT-ROOM-1
™
1-4. SMART CUT 2 OPTIONAL ACCESSORIES REFERENCES
REFERENCES
RK20
SMV415
SMA415
SMB413
SMART CUT 2
(S-CUT 2).
™
integrates three functions for more convenient and easy presentations: SCALER, AUDIO &
®
.
™
is also a state of the art improved SCALER / LINE MULTIPLIER which significantly
™
SMART CUT 2 without option
™
SMART CUT 2 with optional RS-232 interface.
™
SMART CUT 2 with optional D-ILA output format.
™
with optional RS-232 interface and optional D-ILA output format.
Optional ROOM control output for SMART CUT 2
Remote KEYPAD for S-CUT 2-M.
SMART SWITCH VIDEO
SMART SWITCH AUDIO
™
SMART BOOSTER (multiway universal booster).
™
DESIGNATIONS
™
.
DESIGNATIONS
™
: allows to extend up to 18 the video inputs of your S-CUT-M.
™
: allows to extend up to 18 the audio inputs of your S-CUT-M.
Chapter 1 : INTRODUCTION
PAGE 5
