SMART CUT 2™
10-5. COMMANDS DESCRIPTION (continued)
OUTPUT COMMANDS
• u command is used to select the reference sync.
- SMART CUT 2
DECIMAL
VALUE
0
1
2
3
- SMART CUT 2
DECIMAL
VALUE
0
2
3
23
24
25
• O command is used to select the output format.
DECIMAL
VALUE
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
NOTE: The O command is active only if "no computer" is selected as a reference (the response of the n command
should be 0 or 3).
•
o command is used to select the output sync type.
DECIMAL
VALUE
0
1
™
ALONE APPLICATION.
SELECTION
INTERNAL RATE
COMPUTER 1
COMPUTER 2
VIDEO IN RATE
™
+ SMART SWITCH VIDEO
SELECTION
INTERNAL RATE
EXTEND PC 2
VIDEO IN RATE
COMPUTER 1
COMPUTER 2
COMPUTER 3
SELECTION (OUTPUT FORMAT)
VGA (640 x 480) at 60Hz
PLASMA 42" (852 x 480) at 60Hz
SVGA (800 x 600) at 60Hz
MAC (640 x 480) at 66Hz
XGA (1024 x 768) at 60Hz
PLASMA 50" (1280 x 768) at 56Hz
SXGA (1280 x 1024) at 60Hz
VGA (640 x 480) at 75Hz
PLASMA 42" (852 x 480) at 72Hz
SVGA (800 x 600) at 75Hz
MAC 16" (832 x 624) at 75Hz
XGA (1024 x 768) at 75Hz
PLASMA 50" (1280 x 768) at 75Hz
SXGA (1280 x 1024) at 75Hz
D-ILA (1365 x 1024) at 75Hz
SELECTION
(OUTPUT SYNC TYPE)
H & V SEPARATE SYNC.
COMPOSITE SYNC.
RESPONSE
SSYNC0
SSYNC1
SSYNC2
SSYNC3
™
APPLICATION.
RESPONSE
SSYNC0
SSYNC2
SSYNC3
SSYNC23
SSYNC24
SSYNC25
RESPONSE
OFMT0
OFMT1
OFMT2
OFMT3
OFMT4
OFMT5 ALL APPLICATIONS
OFMT6 WITH NO COMPUTER
OFMT7 USED AS REFERENCE
OFMT8 SYNC.
OFMT9
OFMT10
OFMT11
OFMT12
OFMT13
OFMT14
RESPONSE
OSIG0
OSIG1
Chapter 10 : RS-232 PROGRAMMER'S GUIDE
APPLICATION
S-CUT 2
ALONE
APPLICATION
S-CUT 2
+
SMV415
APPLICATION
APPLICATION
ALL
PAGE 33
