SMART CUT 2™

Chapter 2 : INSTALLATION

IMPORTANT:
• Table Top Mounting: The SMART CUT 2
• Rack Mounting:
IMPORTANT:
Please read all the safety instructions (page 2 to 4) before starting.
™
can be used directly on a table: the unit is equipped with 4 plastic feet.
™
The SMART CUT 2 is compatible with a 19" enclosure . Please follow the instructions below to
install the SMART CUT 2
Screw the supplied 19" brackets to the sides of the SMART CUT 2
Attach the SMART CUT 2
not included).
• The openings in the top cover and in the rear panel are for cooling. Do not cover these
openings.
• Be sure that no weight is added to the SMART CUT 2
• The maximum ambient operating temperature must not exceed 40°C (104°F).
• The rack and all mounted equipment in it must be reliably grounded to national and local
electrical codes.
™
into a 19" rack :
™
to the rack by using 4 screws in the front panel holes (screws
Chapter 2 : INSTALLATION
™
.
™
in excess of 2 kg (4.4 lbs.).
PAGE 6
