Dimensions
Dimensions
Figure 30. CI830 FCI Dimensions
Connections
102
Table 23. Power Supply Connections (XI)
Pin
Designation
4
L+
3
L-
2
SA
1
SB
Appendix A Specifications
Description
+24 V d.c. Supply
0 V d.c. Supply
Redundant Power Supply "A"
Monitoring Input
Redundant Power Supply "B"
Monitoring Input
3BSE020926-600
