Commissioning

5 Commissioning

5.1 Safety Instructions

See chapter 2 Safety for general safety instructions.
WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
5 5
connected to AC mains input power. Failure to perform
installation, start-up, and maintenance by qualified
personnel could result in death or serious injury.
•
Installation, start-up, and maintenance must be
performed by qualified personnel only.
Before applying power:
1. Close the cover properly.
2. Check that all cable glands are firmly tightened.
3. Ensure that input power to the unit is off and
locked out. Do not rely on the frequency
converter disconnect switches for input power
isolation.
4. Verify that there is no voltage on input terminals
L1 (91), L2 (92), and L3 (93), phase-to-phase, and
phase-to-ground.
5. Verify that there is no voltage on output
terminals 96 (U), 97 (V), and 98 (W), phase-to-
phase, and phase-to-ground.
Confirm continuity of the motor by measuring Ω
6.
values on U–V (96–97), V–W (97–98), and W–U
(98–96).
7. Check for proper grounding of the frequency
converter and the motor.
8. Inspect the frequency converter for loose
connections on the terminals.
9. Confirm that the supply voltage matches the
voltage of the frequency converter and the
motor.
24
®
VLT Midi Drive FC 280

5.2 Applying Power

Apply power to the frequency converter using the
following steps:
1.
2.
3.
4.

5.3 Local Control Panel Operation

The frequency converter supports numerical local control
panel (NLCP), graphic local control panel (GLCP), and blind
cover. This section describes the operations with NLCP and
GLCP.
NOTICE
The frequency converter can also be programmed from
the MCT 10 Set-up Software on PC via RS485 communi-
cation port or USB port. This software can be ordered
using ordering number 130B1000 or downloaded from
the Danfoss website: drives.danfoss.com/downloads/pc-
tools/#/.

5.3.1 Numeric Local Control Panel (NLCP)

The numerical local control panel (NLCP) is divided into 4
functional sections.
Danfoss A/S © 10/2017 All rights reserved.
Confirm that the input voltage is balanced within
3%. If not, correct the input voltage imbalance
before proceeding. Repeat this procedure after
the voltage correction.
Ensure that any optional equipment wiring
matches the installation application.
Ensure that all operator devices are in the OFF
position. Panel doors must be closed and covers
securely fastened.
Apply power to the unit. Do not start the
frequency converter now. For units with a
disconnect switch, turn it to the ON position to
apply power to the frequency converter.
A. Numeric display.
B. Menu key.
C. Navigation keys and indicator lights (LEDs).
D. Operation keys and indicator lights (LEDs).
