Danfoss VLT Midi Drive FC 280 Operating Manual page 18

Electrical Installation
4 4
1
2
3
4
L1
L2
L3
PE
5
1 PLC
2
Minimum 16 mm
3 Control cables
4 Minimum 200 mm (7.87 in) between control cables, motor
cables, and mains cables.
5 Mains supply
6 Bare (unpainted) surface
7 Star washers
8 Brake cable (shielded)
9 Motor cable (shielded)
Illustration 4.3 Typical Electrical Connection
16
®
VLT Midi Drive FC 280
2 (6 AWG) equalizing cable
Danfoss A/S © 10/2017 All rights reserved.
90
4
4
PE
10 Mains cable (unshielded)
11 Output contactor, and more.
12 Cable insulation stripped
13 Common ground busbar. Follow local and national
requirements for cabinet grounding.
14 Brake resistor
15 Metal box
16 Connection to motor
17 Motor
18 EMC cable gland
6
7
8
9
10
11
12
13
14
15
u
16
v
w
17
18
MG07A402
