Danfoss VLT Midi Drive FC 280 Operating Manual page 27

Commissioning
1
A
Setup 1
2
Status
4
B
Menu
9
C
On
OK
6
Warn
Alarm
8
O
Hand
D
Reset
On
13
Illustration 5.1 View of the NLCP
A. Numeric display
The LCD display is backlit with 1 numeric line. All data is
shown in the NLCP.
The set-up number shows the active set-up and the edit
set-up. If the same set-up acts as both active and edit set-
up, only that set-up number is shown (factory setting).
1
When active and edit set-up differ, both numbers are
shown in the display (for example set-up 12). The number
flashing indicates the edit set-up.
2 Parameter number.
3 Parameter value.
Motor direction is shown at the bottom left of the display.
4
A small arrow indicates the direction.
The triangle indicates whether the LCP is in Status, Quick
5
Menu, or Main Menu.
Table 5.1 Legend to Illustration 5.1, Section A
Setup 1234
n1
p5 p4
INDEX
Illustration 5.2 Display Information
B. Menu key
To select between Status, Quick Menu, or Main Menu,
press [Menu].
MG07A402
Operating Guide
3
5
Quick Main
10
Menu Menu
11
12
10
Auto
On
14 15
AHP
VkW
srpm
Hz%
n2 n3
p3 p2 p1
Danfoss A/S © 10/2017 All rights reserved.
C. Indicator lights (LEDs) and navigation keys
Indicator Light
ON turns on when the frequency
converter receives power from the
6 On Green
mains voltage, a DC bus terminal, or a
24 V external supply.
When warning conditions are met, the
yellow WARN LED turns on, and text
7 Warn Yellow
appears in the display area identifying
the problem.
A fault condition causes the red alarm
8 Alarm Red LED to flash and an alarm text is
shown.
Table 5.2 Legend to Illustration 5.1, Indicator Lights (LEDs)
Key
For moving to the previous step or layer
9 [Back]
in the navigation structure.
For switching between parameter groups,
parameters, and within parameters, or
▲ ▼
10 [ ] [ ] increasing/decreasing parameter values.
Arrows can also be used for setting local
reference.
Press to access parameter groups or to
11 [OK]
enable a selection.
Press to move from left to right within
12 [►] the parameter value to change each digit
individually.
Table 5.3 Legend to Illustration 5.1, Navigation Keys
Function
Function
25
5 5
