Commissioning
D. Operation keys and indicator lights (LEDs)
Key
13 Hand On
14 Off/Reset
5 5
15 Auto On
Table 5.4 Legend to Illustration 5.1, Section D
WARNING
ELECTRICAL HAZARD
Even after pressing the [Off/Reset] key, voltage is present
at the terminals of the frequency converter. Pressing the
[Off/Reset] key does not disconnect the frequency
converter from mains. Touching live parts can result in
death or serious injury.
•
Do not touch any live parts.

5.3.2 The Right-key Function on NLCP

Press [►] to edit any of the 4 digits on the display
individually. When pressing [►] once, the cursor moves to
the first digit, and the digit starts flashing as shown in
Illustration 5.3. Press the [
Pressing [►] does not change the value of the digits, or
move the decimal point.
26
VLT
Function
Starts the frequency converter in local control.
•
An external stop signal by control input or
serial communication overrides the local
hand on.
Stops the motor but does not remove power
to the frequency converter or resets the
frequency converter manually after a fault has
been cleared. If in alarm mode, the alarm is
reset if the alarm condition is removed.
Puts the system in remote operational mode.
•
Responds to an external start command by
control terminals or serial communication.
▲ ▼
] [ ] to change the value.
Danfoss A/S © 10/2017 All rights reserved.
®
Midi Drive FC 280
Illustration 5.3 Right-key Function
[►] can also be used for moving between parameter
groups. When in Main Menu, press [►] to move to the first
parameter in the next parameter group (for example, move
from parameter 0-03 Regional Settings [0] International to
parameter 1-00 Configuration Mode [0] Open loop).
NOTICE
During start-up, the LCP shows the message INITIALISING.
When this message is no longer shown, the frequency
converter is ready for operation. Adding or removing
options can extend the duration of start-up.

5.3.3 Quick Menu on NLCP

The Quick Menu gives easy access to the most frequently
used parameters.
1. To enter Quick Menu, press [Menu] until the
indicator in the display is placed above Quick
Menu.
2. Press [
press [OK].
3.
Press [
Quick Menu.
4. Press [OK] to select a parameter.
5.
Press [
setting.
6. Press [OK] to accept the change.
Setup 1
Setup 1
Setup 1
Setup 1
Setup 1
▲ ▼
] [ ] to select either QM1 or QM2, then
▲ ▼
] [ ] to browse through the parameters in
▲ ▼
] [ ] to change the value of a parameter
