Commissioning
1 [OK]: The first parameter in the group is shown.
▼
2
Press [ ] repeatedly to move down to the parameter.
3 Press [OK] to start editing.
4 [►]: First digit flashing (can be edited).
5 [►]: Second digit flashing (can be edited).
6
[►]: Third digit flashing (can be edited).
▼
7
[ ]: Decrease the parameter value, the decimal point
changes automatically.
▲
8
[ ]: Increase the parameter value.
9 [Back]: Cancel changes, return to 2.
[OK]: Accept changes, return to 2.
5 5
▲ ▼
10
[ ][ ]: Select parameter within the group.
11 [Back]: Remove the value and show the parameter group.
▲ ▼
12
[ ][ ]: Select group.
Table 5.5 Changing Values in Continuous Parameters
For enumerated parameters, the interaction is similar, but
the parameter value is shown in brackets because of the
digits limitation (4 large digits) on the NLCP, and the enum
can be greater than 99. When the enum value is greater
than 99, the LCP can only show the first part of the
bracket.
1
OK
2
OK
Illustration 5.6 Main Menu Interactions - Enumerated
Parameters
1 [OK]: The first parameter in the group is shown.
2 Press [OK] to start editing.
▲ ▼
3
[ ][ ]: Change parameter value (flashing).
4 Press [Back] to cancel changes or [OK] to accept changes
(return to screen 2).
▲ ▼
5
[ ][ ]: Select a parameter within the group.
6 [Back]: Remove the value and show the parameter group.
▲ ▼
7
[ ][ ]: Select a group.
Table 5.6 Changing Values in Enumerated Parameters
30
VLT
Setup 1
Setup 1
Setup 1
Danfoss A/S © 10/2017 All rights reserved.
®
Midi Drive FC 280
Array parameters function as follows:
5 x
1
OK
2
OK
OK
4
Illustration 5.7 Main Menu Interactions - Array Parameters
7
1 [OK]: Show parameter numbers and the value in the first
index.
2 [OK]: Index can be selected.
6
▲ ▼
3
[ ][
4 [OK]: Value can be edited.
5
▲ ▼
5
[ ][
6 [Back]: Cancel changes.
4
OK [OK]: Accept changes.
7 [Back]: Cancel editing index, select a new parameter.
3
▲ ▼
8
[ ][
9 [Back]: Remove parameter index value and show the
parameter group.
▲ ▼
10
[ ][
Table 5.7 Changing Values in Array Parameters
Setup 1
Setup 1
INDEX
Setup 1
INDEX
Setup 1
INDEX
Setup 1
INDEX
]: Select index.
]: Change parameter value (flashing).
]: Select parameter within the group.
]: Select group.
10
9
8
%
%
7
OK
%
6
%
5
