7.3.2.2 Recommended Fuses for UL Compliance

•
The drive modules are supplied with built-in AC fuses. The modules have been qualified for 100 kA short circuit
current rating (SCCR) for the standard busbar configurations at all voltages (380–690 V AC).
•
The drive system is qualified for 100 kA SCCR with any Class L or Class T UL-listed fuses connected at the input
terminals of the drive modules, if no power options or extra busbars are connected externally.
•
The current rating of the Class L or Class T fuses should not exceed the listed fuse rating in Table 7.20 to Table 7.23.
Drive
modules in
system
2
2
2
2
2
7 7
4
4
4
4
4
Table 7.20 12-Pulse Drive Systems (380–500 V AC)
Any minimum 500 V UL-listed fuse can be used for the 380–500 V AC
drive systems.
Drive
modules in
system
2
4
4
4
4
4
Table 7.21 6-Pulse Drive Systems (380–500 V AC)
Any minimum 500 V UL-listed fuse can be used for the 380–500 V AC
drive systems.

7.3.3 Fuse Replacement

If it becomes necessary to replace an AC or DC fuse, refer to the VLT
Drive Modules DC Fuses Installation Instructions.

7.3.4 Short Circuit Current Rating (SCCR)

The drive modules are supplied with built-in AC fuses. The modules have been qualified for 100 kA short circuit current
rating (SCCR) for the standard busbar configurations at all voltages (380–690 V AC). For more information on short-circuit
protection of the drive modules, see chapter 7.3.1 Protection. For more information on the recommended fuses for CE or UL
compliance, see chapter 7.3.2.1 Recommended Fuses for CE Compliance or chapter 7.3.2.2 Recommended Fuses for UL
Compliance, respectively.
