Commissioning
Callout Key
C1 Back
C2 Cancel
C3 Info
C4 OK
4 4
▲ ▼
C5
Table 4.3 Legend to Illustration 4.1, LCP Navigation Keys
D. Indicator lights
Indicator lights are used to identify the drive system status
and to provide a visual notification of warning or fault
conditions.
Callout Indicator Indicator
D1 On
D2 Warn.
D3 Alarm
Table 4.4 Legend to Illustration 4.1, LCP Indicator Lights
E. Operation keys and reset
The operation keys are found toward the bottom of the
local control panel.
Callout Key
E1 Hand On
E2 Off
E3 Auto On
E4 Reset
Table 4.5 Legend to Illustration 4.1, LCP Operation Keys, and
Reset
16
Function
Reverts to the previous step or list in the
menu structure.
Cancels the last change or command as
long as the display mode has not changed.
Shows a definition of the function being
shown.
Accesses parameter groups or enables an
option.
◄► Moves between items in the menu.
Function
light
Green Activates when the drive system
receives power from the mains
voltage or a 24 V external
supply.
Yellow Activates when warning
conditions are active. Text
appears in the display area
identifying the problem.
Red Activates during a fault
condition. Text appears in the
display area identifying the
problem.
Function
Starts the drive system in local control.
An external stop signal by control input
or serial communication overrides the
local hand on.
Stops the motor but does not remove
power to the drive system.
Puts the system in remote operational
mode so it can respond to an external
start command by control terminals or
serial communication.
Resets the drive system manually after a
fault has been cleared.
Danfoss A/S © 08/2017 All rights reserved.
®
VLT Parallel Drive Modules

4.3.3 Menus

4.3.3.1 Quick Menu Mode
The LCP provides access to all parameters listed under the
Quick Menus. To show the list of options in the Quick
Menu, press [Quick Menu].
0.0%
Quick Menus
01 My Personal Menu
02 Quick Setup
05 Changes Made
06 Loggings
Illustration 4.2 Quick Menu View
4.3.3.2 Q1 My Personal Menu
The Personal Menu is used to define the LCP readout
display (see chapter 4.3.2 Layout) and store pre-selected
parameters. Use up to 20 pre-programmed parameters to
store important setup values, thus simplifying on-site
commissioning and fine-tuning for large-scale applications.
These parameters are selected in parameter 0-25 My
Personal Menu.
Parameter
Parameter 0-01 Language
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Parameter 15-51 Frequency Converter Serial
Number
Table 4.6 Q1 My Personal Menu Settings, FC 102
Parameter
Parameter 0-01 Language
Parameter 0-20 Display Line 1.1 Small
Parameter 0-21 Display Line 1.2 Small
Parameter 0-22 Display Line 1.3 Small
Parameter 0-23 Display Line 2 Large
Parameter 0-24 Display Line 3 Large
Parameter 15-51 Frequency Converter Serial
Number
Table 4.7 Q1 My Personal Menu Settings, FC 202
0.00
1(1)
Default setting
English
Reference %
Motor Current
Power [kW]
Frequency
kWh Counter
–
Default setting
English
Reference [Unit]
Analog Input 53
Motor Current
Frequency
Feedback [Unit]
–
