Specifications
Power range
Drive modules
Rectifier configuration
High/normal load
Typical shaft output at 525–550 V [kW]
Typical shaft output at 575 V [hp]
Typical shaft output at 690 V [kW]
Protection rating
Efficiency
Output frequency [Hz]
Heat sink overtemperature trip [°C (°F)]
Power card ambient trip [°C (°F)]
Output current [A]
Continuous (at 550 V)
Intermittent (60 s overload) at 550 V
Continuous (at 575/690 V)
Intermittent (60 s overload) at 575/690 V
Continuous (at 550 V) [kVA]
Continuous (at 575 V) [kVA]
Continuous (at 690 V) [kVA]
Input current [A]
Continuous (at 550 V)
Continuous (at 575 V)
Continuous (at 690 V)
Power losses [W]
Drive modules at 600 V
Drive modules at 690 V
AC busbars at 575 V
DC busbars during regeneration
Maximum cable size [mm 2 (mcm)]
1)
Mains
Motor
Brake
Regeneration terminals
Maximum external mains fuses
Table 7.12 FC 302, 525–690 V AC Mains Supply (2-module System)
1) For 12-pulse units, the cables between the star and delta terminals must be equal in number and length.
MG37L202
User Guide
N250 N315
2 2
HO NO HO
200 250 250
300 350 350
250 315 315
303 360 360
455 396 560
290 344 344
435 378 516
289 343 343
289 343 343
347 411 411
299 355 355
286 339 339
296 352 352
3688 4401 4081
3669 4352 4020
538 540 540
88 88 89
2x120 (250)
2x120 (250)
