Maintenance, Diagnostics, a...
frequency converter is no longer blocked and can be reset
once the cause has been rectified.
Alarms that are not trip locked can also be reset using the
automatic reset function in parameter 14-20 Reset Mode
(Warning: Automatic wake-up is possible.)
If a warning or alarm is marked against a code in Table 6.4,
this means that either a warning occurs before an alarm, or
it is possible to specify whether a warning or an alarm
should be shown for a given fault.
Number Description
1 10 volts low
2 Live zero error
3 No motor
4 Mains phase loss
5 DC-link voltage high
6 DC-link voltage low
7 DC overvoltage
8 DC undervoltage
9 Inverter overloaded
10 Motor ETR overtemperature
11 Motor thermistor overtemperature
12 Torque limit
13 Overcurrent
14 Ground fault
15 Hardware mismatch
16 Short circuit
17 Control word timeout
20 Temp. input error
21 Param error
22 Hoist mech. brake
23 Internal fans
24 External fans
25 Brake resistor short-circuited
26 Brake resistor power limit
27 Brake chopper short-circuited
28 Brake check
29 Heat sink temp
30 Motor phase U missing
31 Motor phase V missing
32 Motor phase W missing
33 Inrush fault
34 Fieldbus communication fault
35 Option fault
36 Mains failure
37 Imbalance of supply voltage
38 Internal fault
MG37L202
User Guide
This is possible, for instance, in parameter 1-90 Motor
Thermal Protection. After an alarm or trip, the motor carries
on coasting, and the alarm and warning flash. Once the
problem has been rectified, only the alarm continues
flashing until the frequency converter is reset.
NOTICE
No missing motor phase detection (numbers 30-32) and
no stall detection are active when parameter 1-10 Motor
Construction is set to [1] PM non-salient SPM.
Warning Alarm/
Trip
X –
(X) (X)
(X) –
(X) (X)
X –
X –
X X
X X
X X
(X) (X)
(X) (X)
X X
X X
X X
– X
– X
(X) (X)
– X
–
(X) (X)
X –
X –
X –
(X) (X)
X X
(X) (X)
X X
(X) (X)
(X) (X)
(X) (X)
X
X X
– –
X X
X
X
Danfoss A/S © 08/2017 All rights reserved.
Alarm/ Parameter
Trip Lock Reference
–
– Parameter 6-01 Live Zero Timeout Function
– Parameter 1-80 Function at Stop
(X) Parameter 14-12 Response to Mains
Imbalance
– –
– –
– –
– –
– –
– Parameter 1-90 Motor Thermal Protection
– Parameter 1-90 Motor Thermal Protection
– –
X –
– –
X –
X –
– Parameter 8-04 Control Word Timeout
Function
– –
X –
– Parameter group 2-2* Mechanical Brake
– –
– –
– –
– Parameter 2-13 Brake Power Monitoring
–
– Parameter 2-15 Brake Check
X
(X) Parameter 4-58 Missing Motor Phase Function
(X) Parameter 4-58 Missing Motor Phase Function
(X) Parameter 4-58 Missing Motor Phase Function
X –
– –
X –
– –
– –
X –
