Installation And Operation; Mounting - Extron electronics AXI 02 AT User Manual

Installation and
Operation
This section describes the AXI 02 AT rear panel connections and front panel controls. The
following topics are covered:
•
•
•
•

Mounting

The 1U high, eighth-rack width, 4.42-inch deep AXI 02 AT mounts in the following manners:
•
•
•
NOTE: To mount the AXI 02 AT using an Extron ZipClip 100 mounting kit, see the
Mounting
Rear Panel Connections
Front Panel Features
Reset Modes
Rack mounting — Attach the device to a standard 19 inch rack shelf. The following
Underwriters Laboratories (UL) guidelines pertain to the installation of the AXI 02 AT in a
rack:
Reduced air flow — Install the equipment in the rack so that the amount of air
•
flow required for safe operation of the equipment is not compromised.
Mechanical loading — Mount the equipment in the racks so that uneven
•
mechanical loading does not create a hazardous condition.
Circuit overloading — When connecting the equipment to the supply circuit,
•
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider equipment nameplate ratings when addressing this
concern.
Reliable earthing (grounding) — Maintain reliable grounding of rack-mounted
•
equipment. Pay particular attention to power supply connections other than direct
connections to the branch circuit (such as the use of power strips).
Under-furniture mounting — Mount the AXI 02 AT under the surface of a desk, table,
or podium.
Free-standing — Set the AXI 02 AT on furniture as desired.
instructions provided with the kit.
AXI 02 AT • Installation and Operation 4
